Preparing for use
4.6 Ensure adequate cooling
1LA5/6/7/9, 1LG4/6, 1MA6/7, 1MB..1/2/3/4/5 - SH 63 ... 355
42 Operating Instructions, 06/2018, A5E44455710A
Table 4- 1 Air guidance
Incorrect
Correct
Minimum dimension "x" for the distance between neighboring modules and the air intake of the m
a-
chine
