Table 7-7 Harmonic currents Single Phase 230 V
Rated Output
(kW)
Fundamental
Amps
3
rd
Amps
5
th
Amps
7
th
Amps
9
th
Amps
11
th
Amps
13
th
Amps
0.12 1.18 1.05 0.9 0.76 0.58 0.568 0.508
0.25 2.26 2.06 1.77 1.50 1.32 1.20 1.02
0.37 3.19 2.26 2.26 2.12 1.83 1.56 1.22
0.55 4.28 3.86 3.18 2.44 1.82 1.42 1.12
0.75 4.52 4.51 3.98 2.98 2.42 1.90 1.44
1.1 8.12 7.80 5.92 4.12 2.96 2.20 1.52
1.5 11.0 9.04 6.40 4.08 2.92 2.16 1.48
2.2 15.7 12.6 8.56 4.56 3.00 2.44 1.28
3.0 19.1 14.4 7.8 3.6 3.28 2.36 0.88
Table 7-8 Derating with Pulse Frequencies
Rated output current in A*
For a pulse frequency of
Rated output
(kW)
2kHz 4kHz 6kHz 8kHz 10kHz 12kHz 14kHz 16kHz
0.12 0.9 0.9 0.9 0.9 0.9 0.9 0.9 0.9
0.25 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7
0.37 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3
0.55 3.2 3.2 3.2 3.2 3.0 2.7 2.5 2.2
0.75 (40ºC) 3.9 3.9 3.9 3.9 3.6 3.3 3.0 2.7
0.75 3.2 3.2 3.2 3.2 3.0 2.7 2.5 2.2
1.1 6.0 6.0 6.0 6.0 5.9 5.7 5.6 5.4
1.5 (40ºC) 7.8 7.8 7.8 7.8 7.6 7.4 7.2 7.0
1.5 6.0 6.0 6.0 6.0 5.9 5.7 5.6 5.4
2.2 11.0 11.0 11.0 11.0 10.8 10.5 10.2 9.9
3.0 (40ºC) 13.6 13.6 13.6 13.6 13.3 12.9 12.6 12.3
3.0 11.0 11.0 11.0 11.0 10.8 10.5 10.2 9.9
The derating for these units are at 50ºC unless otherwise stated.
