Commissioning
4.5 Commissioning with STARTER
Inverter with CU240B-2 and CU240E-2 Control Units
Operating Instructions, 07/2010, FW 4.3.2, A5E02299792B AA
81
● Click on "Load hardware configuration to PG" to save the online setup to your PC and
create an online link between the inverter and PC.
● To conclude your entry, choose "Close".
● The status display changes from the "Offline mode" with blue background into the "Online
mode" with yellow background.
Note
If you click on "Close" without having first run "Load hardware configuration to PG", the
data is not saved and the inverter remains offline.
4.5.7 Basic commissioning
 In the online state, open the STARTER screen of
the Control Unit with a double click and there click
on the "Wizard" button.

Siemens SINAMICS G120 CU240B-2 Specifications

General

Product type designation	SINAMICS G120 CU240B-2
Digital inputs	6
Analog inputs	2
Rated current	According to connected Power Module
Output current	According to connected Power Module
Control Method	Vector control, V/f control
Communication Interfaces	USS, Modbus RTU
Protection Class	IP20
Operating temperature range	-10 to +50 °C
Storage temperature range	-40 to +70 °C
Relative humidity	95% non-condensing
