Table 4-2 Explanation regarding encoder combinations
--- This combination is not permissible.
① Position controllers and speed controllers use the same encoder on the motor shaft.
(QFRGHU
6SHHGFRQWUROOHU3RVLWLRQFRQWUROOHU
7RUTXH
VHWSRLQW
3RVLWLRQ
VHWSRLQW
.
3
7
1
.
3
Depending on the gear ratio, restric‐
tions regarding the accuracy of the
position control.
Not suitable for position control in
the case of mechanical slip on the
load side
② The position controller evaluates an encoder on the motor shaft or on the load side.
The speed controller operates without an encoder.
7RUTXHVHWSRLQWRU
PRWRUYROWDJH
(QFRGHU
6HQVRUOHVVYHFWRUFRQWURORU9I
FRQWURO
3RVLWLRQFRQWUROOHU
3RVLWLRQ
VHWSRLQW
.
3
Restrictions regarding the accuracy
and dynamic performance of the po‐
sition control
Not suitable for the position control
of hoisting gear
The "Travel to 󹪝xed stop" EPos func‐
tion is not possible.
Permissible encoder combinations
Basic positioner
