7.5 Technical data, 200 V inverters
Power Module PM240-2
74 Hardware Installation Manual, 01/2017, A5E33294624B AE
Table 7- 4 PM240-2, IP20, frame size B, 1 AC / 3 AC 200 V … 240 V
Article number without filter
Article number with filter
6SL3210-1PB15-5UL0
6SL3210-1PB15-5AL0
6SL3210-1PB17-4UL0
6SL3210-1PB17-4AL0
6SL3210-1PB21-0UL0
6SL3210-1PB21-0AL0
LO base load power
1.1 kW
1.5 kW
2.2 kW
1 AC LO base load input current
13.5 A
18.1 A
24.0 A
3 AC LO base load input current
7.8 A
9.7 A
13.6 A
LO base load output current
6 A
7.4 A
10.4 A
HO base load power
0.75 kW
1.1 kW
1.5 kW
1 AC HO base load input current
11.8 A
15.8 A
20.9 A
3 AC HO base load input current
5.5 A
7.8 A
9.7 A
HO base load output current
4.2 A
6 A
7.4 A
Fuse according to IEC
Fuse according to UL, class J
3NA3812 (32 A)
35 A
3NA3812 (32 A)
35 A
3NA3812 (32 A)
35 A
Power loss
0.05 kW
0.07 kW
0.12 kW
Required cooling air flow
9.2 l/s
9.2 l/s
9.2 l/s
Weight without filter
2.8 kg
2.8 kg
2.8 kg
Weight with filter
3.1 kg
3.1 kg
3.1 kg
Table 7- 5 PM240-2, PT, frame size B, 1 AC / 3 AC 200 V … 240 V
Article number without filter
Article number with filter
6SL3211-1PB21-0UL0
6SL3211-1PB21-0AL0
LO base load power
2.2 kW
1 AC LO base load input current
24.0 A
3 AC LO base load input current
13.6 A
LO base load output current
10.4 A
HO base load power
1.5 kW
1 AC HO base load input current
20.9 A
3 AC HO base load input current
9.7 A
HO base load output current
7.4 A
Fuse according to IEC
Fuse according to UL, class J
3NA3812 (32 A)
35 A
Power loss
0.12 kW
1)
Required cooling air flow
9.2 l/s
Weight without filter
3.4 kg
Weight with filter
3.7 kg
1) approx. 0.08 through the heatsink
