Technical data
7.5 Technical data, 200 V inverters
Power Module PM240-2
78 Hardware Installation Manual, 01/2017, A5E33294624B AE
Table 7- 12 PM240-2, IP20, frame size F, 3 AC 200 V … 240 V
Article number without filter
6SL3210-1PC31-3UL0
6SL3210-1PC31-6UL0
6SL3210-1PC31-8UL0
LO base load power
37 kW
45 kW
55 kW
LO base load input current
126 A
149 A
172 A
LO base load output current
130 A
154 A
178 A
HO base load power
30 kW
37 kW
45 kW
HO base load input current
110 A
138 A
164 A
HO base load output current
104 A
130 A
154 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3140 (200 A)
175 A
3NA3140 (200 A)
200 A
3NA3142 (224 A)
225 A
Power loss
1.38 kW
1.72 kW
2.09 kW
Required cooling air flow
153 l/s
153 l/s
153 l/s
Weight
57 kg
57 kg
57 kg
7.5.3
Current derating depending on the pulse frequency, 200 V inverters
Article number
LO
power
[kW]
LO base load output current [A]
Pulse frequency [kHz]
2
4
*)
6
8
10
12
14
16
6SL3210-1PB13-0 . L0
0.55
3.2
3.2
2.7
2.2
1.9
1.6
1.4
1.3
6SL321 . -1PB13-8 . L0
0.75
4.2
4.2
3.6
2.9
2.5
2.1
1.9
1.7
6SL3211-1PB15-5 . L0
1.1
6
6
5.1
4.2
3.6
3
2.7
2.4
6SL3210-1PB17-4 . L0
1.5
7.4
7.4
6.3
5.2
4.4
3.7
3.3
3
6SL321 . -1PB21-0 . L0
2.2
10.4
10.4
8.8
7.3
6.2
5.2
4.7
4.2
6SL3210-1PB21-4 . L0
3
13.6
13.6
11.6
9.5
8.2
6.8
6.1
5.4
6SL321 . -1PB21-8 . L0
4
17.5
17.5
14.9
12.3
10.5
8.8
7.9
7
6SL3210-1PC22-2 . L0
5.5
22
22
18.7
15.4
13.2
11
9.9
8.8
6SL3210-1PC22-8 . L0
7.5
28
28
23.8
19.6
16.8
14
12.6
11.2
6SL3210-1PC24-2 . L0 11 42
42
35.7 29.4 25.2 21 18.9 16.8
6SL3210-1PC25-4 . L0
15
54
54
45.9
37.8
32.4
27
24.3
21.6
6SL3210-1PC26-8 . L0 18.5 68
68
57.8 47.6 40.8 34 30.6 27.2
6SL3210-1PC28-0 . L0
22
80
80
68
56
48
40
36
32
6SL3210-1PC31-1 . L0
30
104
104
88.4
72.8
62.4
52
46.8
41.6
6SL3210-1PC31-3 . L0
37
130
130
110.5
91
---
---
---
---
6SL3210-1PC31-6 . L0
45
154
154
130.9
107.8
---
---
---
---
6SL3210-1PC31-8 . L0
55
178
178
151.3
124.6
---
---
---
---
*) Factory setting
The permissible motor cable length depends on the particular cable type and the pulse frequency that
has been selected
