Technical data
7.7 Technical data, 690 V inverters
Power Module PM240-2
92 Hardware Installation Manual, 01/2017, A5E33294624B AE
Table 7- 29 PM240-2, IP20, frame size F, 3 AC 500 V … 690 V
Article number - without filter
Article number - with filter
6SL3210-1PH31-4UL0
6SL3210-1PH31-4AL0
LO base load power
132 kW
LO base load input current
137 A
LO base load output current
142 A
HO base load power
110 kW
HO base load input current
122 A
HO base load output current
115 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3140-6 (200 A)
200 A
Power loss without filter
2.48 kW
Power loss with filter
2.51 kW
Required cooling air flow
153 l/s
Weight without filter
60 kg
Weight with filter
64 kg
7.7.3
Current derating depending on the pulse frequency, 690 V inverters
Article number
LO power [kW]
LO base load output current [A]
Pulse frequency [kHz]
2 *)
4
6SL3210-1PH21-4 . L0
11
14
8.4
6SL3210-1PH22-0 . L0
15
19
11.4
6SL3210-1PH22-3 . L0
18.5
23
13.8
6SL3210-1PH22-7 . L0
22
27
16.2
6SL3210-1PH23-5 . L0
30
35
21
6SL3210-1PH24-2 . L0
37
42
25.2
6SL3210-1PH25-2 . L0
45
52
31.2
6SL3210-1PH26-2 . L0
55
62
37.2
6SL3210-1PH28-0 . L0
75
80
48
6SL3210-1PH31-0 . L0 90
100
60
6SL3210-1PH31-2 . L0
110
115
69
6SL3210-1PH31-4 . L0
132
142
85.2
*) Factory setting
The permissible motor cable length depends on the particular cable type and the pulse frequency that
has been selected
