Configuration
3.3 Configuring the hydraulics
Hydraulic Drive
42 System Manual, 04/2015, 6SL3097-4BA00-0BP1
Symbols, servo solenoid valves
Directly controlled servo solenoid valve NG 6, open
Directly controlled servo solenoid valve NG 6, closed
Precontrolled servo solenoid valve NG 10
Directly controlled HR servo solenoid valve NG 6, open
