Number of digital outputs
Displays number of digital outputs.
P0731[0...2]
BI: Function of digital
output 1
0 - 4294967295 52.3 U, T - CDS U32/
2
Defines source of digital output 1.
An inverse logic can be realized by inverting the digital outputs in P0748.
Output of fault bit 52.3 is inverted on digital output. Therefore, with P0748 = 0, the digital output is set to
low when a fault is triggered, and when there is no fault, it is set to high.
Monitor functions ==> see r0052, r0053
Motor holding brake ==> see P1215
DC-Brake ==> see P1232, P1233
P0732[0...2]
BI: Function of digital
output 2
0 - 4294967295 52.7 U, T - CDS U32/
2
Defines source of digital output 2.
P0733[0...2]
BI: Function of digital
output 3
0 - 4294967295 0 U, T - CDS U32/
2
Defines source of digital output 3.
This digital output is provided by the optional I/O Extension Module.
P0734[0...2]
BI: Function of digital
output 4
0 - 4294967295 0 U, T - CDS U32/
2
Defines source of digital output 4.
This digital output is provided by the optional I/O Extension Module.
r0747.0...1
CO/BO: State of digital
outputs
- - - - - U16 3
Displays status of digital outputs (also includes inversion of digital outputs via P0748).
Digital output 1 energized
Digital output 2 energized
Digital output 3 energized
Digital output 4 energized
Bit = 0 signal: Contacts open
Bit = 1 signal: Contacts closed
The digital output 3 and 4 are provided by the optional I/O Extension Module.
Defines high and low states of digital output for a given function.
The digital output 3 and 4 are provided by the optional I/O Extension Module.
Displays number of analog inputs available.
