Siemens SINAMICS V20 User Manual

Commissioning via the built-in BOP
5.5 Quick commissioning
SINAMICS V20 Converter
Operating Instructions, 10/2019, A5E34559884-012
83
Parameters for
conventional
quick commis-
sioning
Parameters for
estimated quick
commissioning
Function
Setting
P1080[0] P1080[0] Minimum frequency [Hz] Range: 0.00 to 550.00 (factory default: 0.00)
Note:
The value set here is valid for both clockwise and coun-
ter-clockwise rotation.
P1082[0] P1082[0] Maximum frequency [Hz] Range: 0.00 to 550.00 (factory default: 50.00)
Note:
The value set here is valid for both clockwise and coun-
ter-clockwise rotation
P1120[0] P1120[0] Ramp-up time [s] Range: 0.00 to 650.00 (factory default: 10.00)
Note:
The value set here means the time taken for motor to
accelerate from standstill up to the maximum motor
frequency (P1082) when no rounding is used.
P1121[0] P1121[0] Ramp-down time [s] Range: 0.00 to 650.00 (factory default: 10.00)
Note:
The value set here means the time taken for motor to
decelerate from the maximum motor frequency (P1082)
down to standstill when no rounding is used.
P1300[0] P1300[0] Control mode = 0: V/f with linear characteristic (factory default)
= 1: V/f with FCC
= 2: V/f with quadratic characteristic
= 3: V/f with programmable characteristic
= 4: V/f with linear eco
= 5: V/f for textile applications
= 6: V/f with FCC for textile applications
= 7: V/f with quadratic eco
= 19: V/f control with independent voltage setpoint
P3900 = 3 P3900 = 3 End of quick commission-
ing
= 0: No quick commissioning (factory default)
= 1: End quick commissioning with factory reset
= 2: End quick commissioning
= 3: End quick commissioning and initiate motor data
calculation
Note:
After completion of calculation, P3900 and P0010 are
automatically reset to their original value 0.
The converter displays "8.8.8.8.8" which indicates that it
is busy with internal data processing.
P1900 = 2 P1900 = 2 Select motor data identifi-
cation
= 0: Disabled (factory default)
= 2: Identification of all parameters in standstill

Siemens SINAMICS V20 Specifications

General

Power Range	0.12 kW to 30 kW
Overload Capacity	150% for 60 seconds
Protection Class	IP20
Storage Temperature Range	-40°C to +70°C
Altitude	Up to 1000 m without derating
Input Voltage	3AC 380 V to 480 V
Output Voltage	0 V to Input Voltage
Control Modes	V/f control
Ambient Temperature Range	-10°C to +60°C
Relative Humidity	5% to 95%, non-condensing
Communication Interfaces	Modbus RTU
Braking Resistor	Optional external
