Siemens SINUMERIK 802C base line User Manual

Technical Appendix
SINUMERIK 802C base line
6-19
Start-Up
3000
Data block
Mode signals to CNC [r/w]
Interface PLC -----> CNC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Mode Mode
30000000 Reset Change
lock JOG MDA AUTOM.
Machine function
30000001
REF TEACH
IN
30000002
30000003
3100
Data block
Mode signals from CNC [r]
Interface CNC -----> PLC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Active mode
31000000
READY JOG MDA
AUTOM.
Active machine function
31000001
REF TEACH
