Installing the Control System
2-8
SINUMERIK 802C base line
Start-Up
2.3 Connecting the individual components
Connecting the components
Please note the following:
Notice
Use only shielded cable and make sure that the shield is connected to the
metal or metal plated connector casing on the control side. For the purpose of
isolating the analog setpoint signal from low-frequency interference, we
recommend not to ground the shield on the drive side.
The preassembled cable offered as accessories provides optimum protection
against interference.
General procedure:
Proceed as follows to connect the individual components:
1. Connect the cables to the components as shown in Fig. 2–4 or Fig. 2-5.
2. Fix the sub-D connector in place using the knurled screws.
2.3.1 Connecting the feed drives and the spindle (X7)
Pin assignments For connector on the CNC side
Feed drive interface
Connector designation: X7
AXIS 1–4
Connector type: 50-pin sub-D plug connector
Table 2-1 Pin assignments of connector X7
X7
Pin Signal Type Pin Signal Type Pin Signal Type
1 AO1 AO 18 n.c. 34 AGND1 AO
2 AGND2 AO 19 n.c. 35 AO2 AO
3 AO3 AO 20 n.c. 36 AGND3 AO
4 AGND4 AO 21 n.c. 37 AO4 AO
5 n.c. 22 M VO 38 n.c.
6 n.c. 23 M VO 39 n.c.
7 n.c. 24 M VO 40 n.c.
8 n.c. 25 M VO 41 n.c.
9 n.c. 26 n.c. 42 n.c.
10 n.c. 27 n.c. 43 n.c.
11 n.c. 28 n.c. 44 n.c.
12 n.c. 29 n.c. 45 n.c.
13 n.c. 30 n.c. 46 n.c.
14 SE1.1 K 31 n.c. 47 SE1.2 K
15 SE2.1 K 32 n.c. 48 SE2.2 K
16 SE3.1 K 33 n.c. 49 SE3.2 K
17 SE4.1 K 50 SE4.2 K
