Siemens SINUMERIK 802C base line

Technical Appendix
SINUMERIK 802C base line
6-5
Start-Up
14514 USER_DATA_FLOAT [n]
– User data (Float) 0 ... 7 POWER ON
– 0.0 ... ... DOUBLE 2/7
14516 USER_DATA_PLC_ALARM [n]
– User data (Hex) Alarm bit 0 ... 31 POWER ON
– 0 0 0xFF BYTE 2/7
6.1.3 Channel–specific machine data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
20210 CUTCOM_CORNER_LIMIT
Degrees Maximum angle for compensation blocks with TRC POWER ON
_always 100 0.0 150. DOUBLE 2/7
20700 REFP_NC_START_LOCK
– NC–Start disable without reference point RESET
_always 1 0 1
BOOLEAN
2/7
21000 CIRCLE_ERROR_CONST
mm Circle end point monitoring constant POWER ON
_always 0.01 0.0 plus DOUBLE 2/7
22000 AUXFU_ASSIGN_GROUP
– Auxiliary function group (aux. fct. no. in channel): 0...49 POWER ON
_always 1 1 15 BYTE 2/7
22010 AUXFU_ASSIGN_TYPE
– Auxiliary function type (aux. fct. no. in channel): 0...49 POWER ON
_always , , – – STRING 2/7
22030 AUXFU_ASSIGN_VALUE
– Auxiliary function value (aux. fct. no. in channel): 0...49 POWER ON
_always 0 – – DWORD 2/7
22550 TOOL_CHANGE_MODE
– New tool compensation for M function POWER ON
_always 0 0 1 BYTE 2/7
27800 TECHNOLOGY_MODE
– Technology in the channel (value=0: milling, value=1:
turning)
NEW CONF
1 0 1 BYTE 2/7
