Technical Appendix
6-4 SINUMERIK 802C base line
Start-Up
6.1.2 General machine data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
10074 PLC_IPO_TIME_RATIO
– PLC task factor for main run POWER ON
2150DWORD2/7
10240 SCALING_SYSTEM_IS_METRIC
– Basic system metric POWER ON
_always 1 *** ***
BOOLEAN
2/7
11100 AUXFU_MAXNUM_GROUP_ASSIGN
– Number of auxiliary functions distr. amongst aux. fct.
groups
POWER ON
_always 1 1 50 BYTE 2/7
11200 INIT_MD
HEX Standard machine data loaded on next Power On POWER ON
_always 0x0F – – BYTE 2/7
11210 UPLOAD_MD_CHANGE_ONLY
HEX Saving only of modified MD (value=0: complete= no
difference)
RESTART
- 0x0F - - BYTE 2/7
11310 HANDWH_REVERSE
– Threshold for direction change handwheel POWER ON
_always 2 0.0 plus BYTE 2/7
11320 HANDWH_IMP_PER_LATCH
– Handwheel pulses per detent position (handwheel
number): 0...1
POWER ON
_always 1., 1. – – DOUBLE 2/7
11346 HANDWH_TRUE_DISTANCE
– Handwheel POWER ON
_always 0 0 3 BYTE 2/2
14510 USER_DATA_INT [n]
kB User data (INT) 0 ... 31 POWER ON
_always – 0 – DWORD 2/7
14512 USER_DATA_HEX [n]
kB User data (Hex) 0 ... 31 POWER ON
– 0 0 0xFF BYTE 2/7
