Siemens SINUMERIK 802C base line User Manual

Technical Appendix
SINUMERIK 802C base line
6-3
Start-Up
278 $MM_NCK_SYSTEM_FUNC_MASK
Decimal Option data to enable system-specific functions
POWER ON
2/2
0 0 0 15 Byte
280 $MM_V24_PPI_ADDR_PLC
Decimal PPI address of the PLC
POWER ON
3/3
0 2 0 126 BYTE
281 $MM_V24_PPI_ADDR_NCK
Decimal PPI address of the NCK
POWER ON
3/3
0 3 0 126 BYTE
282 $MM_V24_PPI_ADDR_MMC
Decimal PPI address of the HMI
POWER ON
3/3
0 4 0 126 BYTE
283 $MM_V24_PPI_MODEM_ACTIVE
Decimal Modem active
Immediately
3/3
0 0 0 1 BYTE
284 $MM_V24_PPI_MODEM_BAUD
Decimal Modem baud rate
Immediately
3/3
0 7 5 9 BYTE
285 $MM_V24_PPI_MODEM_PARITY
Decimal Modem parity
Immediately
3/3
0 0 0 2 BYTE
288 $MM_STARTUP_PICTURE_TIME
Decimal Average time of start up picture visibility in
second
POWER ON
2/2
0 5 0 10 BYTE
