Siemens SINUMERIK 802C base line User Manual

Technical Appendix
SINUMERIK 802C base line
6-15
Start-Up
6.1.5 Setting data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
41110 JOG_SET_VELO
mm/min Axis speed for JOG Immediately
_always 0.0 0.0 plus DOUBLE 4/4
41200 JOG_SPIND_SET_VELO
rev/min Speed for spindle JOG mode Immediately
_always 0.0 0.0 plus DOUBLE 4/4
43210 SPIND_MIN_VELO_G25
rev/min Progr. spindle speed limitation G25 Immediately
_always 0.0 0.0 plus DOUBLE 4/4
43220 SPIND_MAX_VELO_G26
rev/min Progr. spindle speed limitation G26 Immediately
_always 1000 0.0 plus DOUBLE 4/4
43230 SPIND_MAX_VELO_LIMS
rev/min Spindle speed limitation with G96 Immediately
_always 100 0.0 plus DOUBLE 4/4
52011 STOP_CUTCOM_STORE
Alarm response for TRC and feedforward stop Immediately
–1 0 1
BOOLEAN
4/4
