Start-Up
4-32
SINUMERIK 802C base line
Start-Up
4.5 User Interface
This interface includes all signals between CNC/PLC and HMI/PLC. In addition,
the PLC decodes the auxiliary function commands for straightforward further
processing in the user program.
4.6 Technology Setting
Overview
The SINUMERIK 802C base line is supplied with the default machine data as a
control system for turning machines (2 axes, 1 spindle). If you wish to set
another technology (e.g. milling), the relevant machine data file must be loaded
from the tool box into the control system.
The file with the technology machine data must be loaded after the control
system has booted successfully, but prior to commissioning.
Sequence of operations
To change the technology setting, proceed as follows:
z
Make a V24 link between PG/PC and the control system.
z
Turn on the control system and wait until it has booted without errors.
z
Press the Start data inp. softkey in the Services menu (use the V24
default interface settings).
z
Select the technology machine data file techmill.ini (included in the
toolbox) required for milling and transfer it to the PG/PC using WinPCIN.
z
After the file has been transferred correctly, carry out POWER ON.
z
The SINUMERIK 802C base line is now preset to the desired technology.
Example: techmill. ini
Default: 3 axes (X, Y and Z), 1 spindle, no transversal axis, G17 etc.
If you wish to reconfigure a SINUMERIK 802C base line control system to
turning, carry out POWER ON with the default machine data (start-up switch
position 1).
Notice
All memory areas are initialized or loaded with stored default values (machine
data).
The basic configuration of the SINUMERIK 802C must be carried out during
the commissioning prior to the general configuration (MD input).
This need not to be done when series start-up is carried out. The configured
machine data are contained in the series start-up file.
