Start-Up
SINUMERIK 802C base line
4-31
Start-Up
The loaded PLC user program is transferred from the permanent memory to
the user memory when the control is booted next time; it will be active from this
moment.
Upload
The PLC applications can be saved using the PLC 802 Programming Tool or
the tool WINPCIN.
z
Upload PLC project using the PLC 802 Programming Tool (Step 7
connect on)
Read out the project from the control system to reconstruct the current
project in the PLC 802 Programming Tool.
z
Series start-up “Start-up Data” using the tool WINPCIN (PLC MD, PLC
Project and user alarm texts) Data Out
z
Read out PLC applications using the Tool WINPCIN (PLC Project
information and user alarm texts) Data Out
Compare
The project in the PLC 802 Programming Tool is compared with the project
contained in the permanent memory (load memory) of the CNC.
Versions display
Calling via the softkey Diagnosis / Service Display / Version(PROJECT)
The transmitted project including user program, which is active in the PLC after
the control system has powered up.
The programmer can use the first comment line in the program title of the PLC
802 Programming Tool for his own additional information in the version display
(see “View Properties“).
