Siemens SINUMERIK 802C base line User Manual

Start-Up
SINUMERIK 802C base line
4-45
Start-Up
Interface signals of the spindle
Interface signals
“Speed change” 39032000 Bit 3
“Actual gear stage” 38032000 bits 0 to 2
“No speed monitoring on gear change”
38032000 bit 6
“Speed is changed” 38032000 Bit 3
“Set gear stage” 39032000 bits 0 to 2
“Positioning mode” 39032002 bit 5
“Oscillating through PLC”38032002 bit 4
“Oscillating mode” 39032002 bit 6
“Control mode” 39032002 bit 7
“Traversing minus” 39030004 bit 6
“Traversing plus” 39030004 bit 7
Reciprocation mode for gear change
The reciprocation mode of the spindle is intended to facilitate the gear change.
For reciprocation mode, the following axis MD and interface signals are
relevant:
MD Description
35400 Reciprocation speed
35410 Acceleration when reciprocating
35430 Start direction in reciprocation
35440 Reciprocation time for M3 direction
35450 Reciprocation time for M4 direction
Interface signals “Change gear” 39032000 bit 3
“Reciprocation speed” 38032002 bit 5
“Reciprocating by PLC” 38032002 bit 4
“Set direction of rotation CCW” 38032002 bit 7
