Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
G810
6)
, ..., G819 G G group reserved for the OEM user + PM-NC
G820
6)
, ..., G829 G G group reserved for the OEM user + PM-NC
G931 G Feedrate specified by means of traversing
time, deactivate constant path velocity
m +
G942 G Freeze linear feedrate and constant cutting
rate or spindle speed
m +
G952 G Freeze revolutional feedrate and constant cut‐
ting rate or spindle speed
m +
G961 G Linear feedrate (as for G94) and constant cut‐
ting rate
m + PM-NC
G962 G Linear feedrate or revolutional feedrate and
constant cutting rate
m + PM-NC
G971 G Linear feedrate and constant spindle speed
(constant cutting rate OFF)
m + PM-NC
G972 G Linear feedrate or revolutional feedrate and
constant spindle speed (constant cutting rate
OFF)
m + PM-NC
G973 G Revolutional feedrate without spindle speed
limitation and constant spindle speed (G97
without LIMS for ISO mode)
m + PM-NC
GEOAX P Assign new channel axes to geometry axes 1 -
3
+ - PM-NC
GET P Replace enabled axis between channels + + PM-NC
GETACTT F Gets active tool from a group of tools with the
same name
+ - FM-TM
GETACTTD F Gets the T number associated with an abso‐
lute D number
+ - PM-NC
GETD P Replace axis directly between channels + - PM-NC
GETDNO F Returns the D number of a cutting edge (CE)
of a tool (T)
+ - PM-NC
GETEXET P Reading of the loaded T number + - FM-TM
GETFREELOC P Find a free space in the magazine for a given
tool
+ - FM-TM
GETSELT P Return selected T number + - FM-TM
GETT F Get T number for tool name + - FM-TM
GETTCOR F Read out tool lengths and/or tool length com‐
ponents
+ - PM-NC
GETTENV F Read T, D and DL numbers + - PM-NC
GETVARAP F Read access rights to a system/user variable + - PM-NC
GETVARDFT F Read default value of a system/user variable + - PM-NC
GETVARLIM F Read limit values of a system/user variable + - PM-NC
GETVARPHU F Read physical unit of a system/user variable + - PM-NC
GETVARTYP F Read data type of a system/user variable + - PM-NC
GFRAME0 ...
GFRAME100
G Activation of the grinding frame <n> of the da‐
ta management in channel
m + PM-NC
Tables
4.1 Operations
NC programming
1216 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
