Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
GOTO K Jump operation first forward then backward
(direction initially to end of program and then
to beginning of program)
+ PM-NC
GOTOB K Jump backward (toward the beginning of the
program)
+ PM-NC
GOTOC K As GOTO, but suppress alarm 14080 "Jump
destination not found"
+ PM-NC
GOTOF K Jump forward (toward the end of the program) + PM-NC
GOTOS K Jump back to beginning of program + PM-NC
GP K Keyword for the indirect programming of posi‐
tion attributes
+ PM-NC
GROUP_
ADDEND
C (T) End of trial cut addition + PM-NC
GROUP_BEGIN C (T) Beginning of program group + PM-NC
GROUP_END C (T) End of program group + PM-NC
GWPSOF P Deselect constant grinding wheel peripheral
speed (GWPS)
s + - PM-NC
GWPSON P Select constant grinding wheel peripheral
speed (GWPS)
s + - PM-NC
H... A Auxiliary function output to the PLC + + PM-NC, FM-B
HOLES1 C (T) Row of holes + PM-NC
HOLES2 C (T) Circle of holes + PM-NC
I A Interpolation parameters s + PM-NC
I1 A Intermediate point coordinate s + PM-NC
IC K Incremental dimensions s + PM-NC
ICYCOF P All blocks of a technology cycle are processed
in one interpolation cycle following ICYCOF
+ + FM-SA
ICYCON P Each block of a technology cycle is processed
in a separate interpolation cycle following ICY‐
CON
+ + FM-SA
ID K Identifier for modal synchronous actions m - + FM-SA
IDS K Identifier for modal static synchronous actions - + FM-SA
IF K Introduction of a conditional jump in the part
program/technology cycle
+ + PM-NC
INDEX F Define index of character in input string + - PM-NC
INICF K Initialization of variables for NEWCONF + PM-NC
INIPO K Initialization of variables at POWER ON + PM-NC
INIRE K Initialization of variables at reset + PM-NC
INIT P Selection of a particular NC program for exe‐
cution in a particular channel
+ - PM-NC
INITIAL Generation of an INI file across all areas + PM-NC
INT K Data type: Integer with sign + PM-NC
INTERSEC F Calculate intersection between two contour
elements
+ - PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1217
