Protection areas
Identifier Parameter Explanation
1. 2. 3. 4. 5.
CPROTDEF INT:
Number of the
protection
area
BOOL:
TRUE:
Tool-related
protection
area
INT:
0:
4th and 5th
parameters
are not evalu‐
ated
1:
4th parameter
is evaluated
2:
5th parameter
is evaluated
3:
4th and 5th
parameters
are evaluated
REAL: Limit in
plus direction
REAL: Limit in
minus direc‐
tion
Definition of a channel-
specific protection area
NPROTDEF INT:
Number of the
protection
area
BOOL:
TRUE:
Tool-related
protection
area
INT:
0:
4th and 5th
parameters
are not evalu‐
ated
1:
4th parameter
is evaluated
2:
5th parameter
is evaluated
3:
4th and 5th
parameters
are evaluated
REAL: Limit in
plus direction
REAL: Limit in
minus direc‐
tion
Definition of a ma‐
chine-specific protec‐
tion area
Tables
4.4 Predefined procedures
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1273
