AXCONF_MACHAX_USED [0] = 1; 1st MA is the 1st axis in the channel
AXCONF_MACHAX_USED [1] = 2; 2nd MA is the 2nd axis in the channel
AXCONF_MACHAX_USED [2] = 0; gap in the list ...
AXCONF_MACHAX_USED [3] = 3; ... of the channel axes
Axis identifiers must be defined in the corresponding list places of
AXCONF_CHANAX_NAME_TAB for the axes activated in the channel.
Related to:
MD20080 $MC_AXCONF_CHANAX_NAME_TAB
Reference:
Description of Functions B3.
20080 AXCONF_CHANAX_NAME_TAB C01, C11, C10 F2, V2, M1, K2, V1
- Channel axis name in channel STRING PowerOn
-
808d-me42 4 X, Y, Z, SP - - 2/2 M
808d-me62 5 X, Y, Z, SP, A - - 2/2 M
808d-te42 4 X, Z, SP, C - - 2/2 M
808d-te62 5 X, Z, SP, C, Q - - 2/2 M
808d-mte40 4 X, Y, Z, A, B, C, U,
V,
X11, Y11,,
X, Y, Z,
A, B, ...
- - 2/2 M
808d-mte60 20 X, Y, Z, A, B, C, U,
V, X11, Y11,,
X, Y, Z,
A, B, ...
- - 2/2 M
Description: The name of the channel axis/special axis is entered in this MD. Normally the first
three channel axes are assigned by the three assigned geometry axes
The remaining channel axes are also called special axes. The channel axis/special axis
at the screen in the Work (workpiece coordinate system) is always displayed with the
name entered in this MD.
Special cases:
● The specified channel axis name/special axis name must not conflict with the
designation and assignment of the machine and geometry axis names or other
identifiers.
● The
channel axis
name entered must not include any of the following reserved address
letters:
- D Tool offset (D function) - E Reserved
- F Feedrate (F function) - G Path condition
- H Auxiliary function (H function) - L Subroutine call
- M Miscellaneous function (M function) - N Subblock
- P Subroutine number of passes - R Arithmetic parameters
- S Spindle speed (S function) - T Tool (T function)
● The name must not include any keywords (e.g. DEF, SPOS etc.) or pre-defined
identifiers (e.g. ASPLINE, SOFT).
● The use of an axis identifier consisting of a valid address letter (A, B, C, I, J,
K, Q, U, V, W, X, Y, Z) followed by an optional numerical extension (1-99) gives
slightly better block cycle times than a general identifier.
● No special names need be entered in this MD for channel axes to which geometry axes
are assigned (normally the first three channel axes).
Axis identifiers that are not allowed are rejected with an alarm during runup.
Machine data
3.3 Channel-specific machine data
Parameter Manual
112 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
