Siemens SINUMERIK 808D ADVANCED Parameter Manual

4001 Pulse ena‐
ble
Integrator
disable
speed con‐
troller
4002
4003
Signals to technology functions
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
5000 Torque
equaliza‐
tion control‐
ler on
5001
5002
5003 Stop
HIAxMove
Resume
DEPMCS
5004
5005
5006 (spin‐
dle)
Spindle po‐
sitioning
Automatic
gear stage
change
Setpoint direction of rota‐
tion
Spindle
stop
Counter-
clockwise
Clockwise
5007 (cou‐
plings)
Delete syn‐
chronism
override
5008 (SISI-
TECH)
5009 (SISI-
TECH)
5010
5011
6.9.3 Signals from axis/spindle
General signals from axis/spindle
DB3900 ...
3903
Signals from axis/spindle [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PLC user interface
6.9 Axis/spindle signals
Parameter Manual
478 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
