6.11 Signals, synchronized actions
6.11.1
Signals, synchronized actions to channel
DB4600
Signals, synchronized actions to channel [r/w]
PLC -> HMI interface
Byte Bit 7
Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Deactivate synchronized action with ID...
ID8 ID7 ID6 ID5 ID4 ID3 ID2 ID1
1 Deactivate synchronized action with ID...
ID16 ID15 ID14 ID13 ID12 ID11 ID10 ID9
2 Deactivate synchronized action with ID...
ID24 ID23 ID22 ID21 ID20 ID19 ID18 ID17
6.11.2 Signals, synchronized actions from channel
DB4700 Signals, synchronized actions from channel [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Synchronized action with ID...can be blocked from the PLC
ID8 ID7 ID6 ID5 ID4 ID3 ID2 ID1
1 Synchronized action with ID...can be blocked from the PLC
ID16 ID15 ID14 ID13 ID12 ID11 ID10 ID9
2 Synchronized action with ID...can be blocked from the PLC
ID24 ID23 ID22 ID21 ID20 ID19 ID18 ID17
6.11.3 Reading and writing PLC variables
DB4900 PLC variables [r/w]
PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Offset [0]
1 Offset [1]
2 Offset [2]
… …
4094 Offset [4094]
4095 Offset [4095]
PLC user interface
6.11 Signals, synchronized actions
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 483
