248 Interval 32 [h]
250 Time of first warning 32 [h]
252 Number of warnings to be output 32
254 Reserved 32
6.13.2 Actual data
DB9904 Actual data table [r16]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Interval 1 [h]
2 Number of warnings to be output 1
4 Reserved_1 1
6 Reserved_2 1
8 Interval 2 [h]
10 Number of warnings to be output 2
11 Reserved_1 2
14 Reserved_2 2
... ...
248 Interval 32 [h]
250 Number of warnings to be output 32
252 Reserved_1 32
254 Reserved_2 32
6.14 User interface for ctrl energy
Table 6-1 Energy saving profile
DB9906 Ctrl energy
Byte Bit 7
Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Control signals
Set time to
pre-warn‐
ing limit
Immediate‐
ly activate
energy sav‐
ing profile
1 Control signals (HMI -> PLC)
Immediate‐
ly activate
energy sav‐
ing profile
2 Signals to check/test the energy-saving profile
PLC user
signal
Master
computer
signal
PLC user interface
6.14 User interface for ctrl energy
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 485
