6.9 Axis/spindle signals
6.9.1
Transferred M and S functions, axis specific
DB3700 … 3703
M, S functions [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 M function for spindle (DINT)
4 S function for spindle (REAL)
6.9.2 Signals to axis/spindle
Common signals to axis/spindle
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Feedrate override
H G F E D C B A
1 Override
active
Position
measuring
system 2
Position
measuring
system 1
Follow up
mode
Axis spin‐
dle disable
2 Reference point value Clamping
in progress
Distance-
to-go/spin‐
dle reset
Drive ena‐
ble
4 3 2 1
3 Axis/spin‐
dle enable
program
test
Velocity/
spindle
speed limit‐
ing
Activate fixed feedrate Enable ap‐
proach to
fixed stop
Feed 4 Feed 3 Feed 2 Feed 1
4 Traversing keys Rapid tra‐
verse over‐
ride
Traverse
key disable
Feedrate
stop/spin‐
dle stop
Activate handwheel
Plus Minus 2 1
5 Machine function
1)
Continuous
traversing
Var. INC 1000 INC 1000 INC 100 INC 10 INC 1 INC
6
7 Contour-
handwheel
direction of
rotation in‐
verted
8
9
PLC user interface
6.9 Axis/spindle signals
Parameter Manual
476 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
