Siemens SINUMERIK 808D ADVANCED

6.2.5 PI service: Result
DB1200 Reading / writing NC data [r]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
5000 Error in job Job com‐
pleted
5001
5002
6.3 Retentive data area
DB1400 Retentive data [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
User data
0
User data
1
User data
2
...
...
32
...
...
User data
126
User data
127
6.4 User Alarms
6.4.1 User alarms: Activating
DB1600 Activating alarm [r/w]
PLC -> HMI interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PLC user interface
6.4 User Alarms
Parameter Manual
456 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
