Siemens SINUMERIK 808D ADVANCED Parameter Manual

0 EMER‐
GENCY
OFF active
1 Inch meas‐
uring sys‐
tem
Probe actuated
Probe 2 Probe 1
2 NC ready Drive ready Drives in cy‐
clic opera‐
tion
3 Air temper‐
ature alarm
NCK alarm
is active
4
5
6
7
8
9
10
11
12 Change counter for motion, handwheel 1
13 Modification counter for motion, handwheel 2
14
15 Change counter , inch/metric measuring system
16
17
18
19
6.7.3 Signals at fast inputs and outputs
DB2800 Signals at fast inputs and outputs [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Block digital NCK inputs
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
1001 Value from PLC for NCK inputs
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
1008 Block digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
1009 Overwrite mask for digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
1010 Value from PLC for digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
PLC user interface
6.7 NCK signals
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 467
