The machine function
is only entered if the signal "INC inputs in the operating-mode signal range active" (DB2600.DBX1.0)
is set.
Signals to axis
DB3800 ...
3803
Signals to axis [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Delay Ref.
pt. ap‐
proach
Module lim‐
it enabled
Software limit switch Hardware limit switch
Plus Minus Plus Minus
1001
1002 Activate
program
test
Suppress
program
test
1003
Signals to spindle
DB3800 ...
3803
Signals to axis [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
2000 Delete S
value
No speed
monitoring
for gear
change
Resynchronize spindle Gear
changed
Actual gear stage
2 1 C B A
2001 Invert M3/
M4
Re‐
synchron‐
ize during
positioning
Feedrate
override for
spindle val‐
id
2002 Setpoint direction of rota‐
tion
Oscillation
speed
Oscillation
controlled
by PLC
Counter-
clockwise
Clockwise
2003 Spindle override
H G F E D C B A
Signals to drive
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
4000 Holding
brake
PLC user interface
6.9 Axis/spindle signals
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 477
