MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
20096 T_M_ADDRESS_EXT_IS_SPINO C01, C04, C09 H2, W1
- Meaning of address extension at T, M tool change BOOLEAN PowerOn
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
Description: This MD is only significant if the functions 'Tool management'/'flat D numbers' are
inactive.
FALSE
The contents of the address extensions of the NC addresses T and M 'tool change command
number' are not evaluated by the NCK. The PLC decides on the significance of the
programmed extension.
TRUE
The address extensions of the NC addresses T and M 'tool change command number' - 'tool
change command number'=TOOL_CHANGE_M_CODE with 6 as the default value - are
interpreted as spindle numbers.
NCK treats the extension in the same way as the active functions 'tool management' and
'flat D number management'.
That is, the programmed D number always refers to the T number of the programmed main
spindle number.
See also:
MD20090 $MC_SPIND_DEF_MASTER_SPIND,
MD22550 $MC_TOOL_CHANGE_MODE,
MD22560 $MC_TOOL_CHANGE_M_CODE
20098 DISPLAY_AXIS EXP, C01 -
- Display axis on HMI DWORD Immediately
-
808d-me42 4 0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,, 0x7...
0 0x7FFFFFFF 1/1 M
808d-me62 5 0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,, 0x7...
0 0x7FFFFFFF 1/1 M
808d-te42 4 0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,, 0x7...
0 0x7FFFFFFF 1/1 M
808d-te62 4 0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,, 0x7...
0 0x7FFFFFFF 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
114 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
