GCODE_RESET_VALUES[61] 62 1 (inactive)
GCODE_RESET_VALUES[62] 63 1 (inactive)
GCODE_RESET_VALUES[63] 64 1 (GS0)
: : :
GCODE_RESET_VALUES[69] 70 1 (not defined)
20152 GCODE_RESET_MODE C03 M1, K1, K2, P1
- Reset response of G groups BYTE Reset
-
808d-me42 70 0, 0, 0, 0, 0, 0, 0, 1, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,
0 1 1/1 M
808d-me62 70 0, 0, 0, 0, 0, 0, 0, 1, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,
0 1 1/1 M
808d-te42 70 0, 0, 0, 0, 0, 0, 0, 1, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,
0 1 1/1 M
808d-te62 70 0, 0, 0, 0, 0, 0, 0, 1, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,
0 1 1/1 M
808d-mte40 70 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,, ...
0 1 1/1 M
808d-mte60 70 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,, ...
0 1 1/1 M
Description: This MD is only evaluated if bit 0 is set in MD20110 $MC_RESET_MODE_MASK.
For each entry in MD20150 $MC_GCODE_RESET_VALUES (that is for each G group), this MD
is used to determine whether, on reset/part program end, the setting in MD20150
$MC_GCODE_RESET_VALUES is used again (MD = 0) or the current setting is retained (MD
= 1).
Example:
Here, the basic setting for the 6th G group (current plane) is read from MD20150
$MC_GCODE_RESET_VALUES at each reset / part program end:
MD20150 $MC_GCODE_RESET_VALUES[5]=1 ; reset value of the 6th G group is G17
MD20152 $MC_GCODE_RESET_MODE[5]=0 ; basic setting for 6th G group corresponds, after;
reset / part program end; to MD20150 $MC_GCODE_RESET_VALUES[5]
However, if the current setting for the 6th G group (current plane) is to be retained
after reset / part program end, then the following setting results:
MD20150 $MC_GCODE_RESET_VALUES[5]=1 ; reset value of the 6th G group is M17
MD20152 $MC_GCODE_RESET_MODE[5]=1 ; current setting for 6th G group
;is retained even after reset / part program end.
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
20154 EXTERN_GCODE_RESET_VALUES C11, C03 -
- Initial setting of G groups in ISO mode BYTE Reset
-
808d-me42 31 1, 1, 1, 2, 1, 1, 1, 3, 4,
1, 1, 2, 2, 1, 3, 2, 1, 0,
1, 1, 1,, ...
0 - 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 131
