> 0 Number of the total offset
= 0 No total offset active with D programming
= 1 The total offset number for the previously programmed D is used.
Related to:
MD20270 $MC_CUTTING_EDGE_DEFAULT.
20310 TOOL_MANAGEMENT_MASK C09 P3 pl, P3 sl
- Activation of tool management functions DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0xFFFFFFF 1/1 M
Description: MD = 0: Tool management inactive
Bit 0 to bit4
Bit 0=1: Tool management active
Tool management functions are enabled for the current channel.
Bit 1=1: Tool monitoring function active
The functions for monitoring the tools (tool life and guantity) are enabled.
Bit 2=1: OEM functions active
Bit 3=1: Consider adjacent location active
Bit 0 to bit 3 must be set as in MD18080 $MN_MM_TOOL_MANAGEMENT_MASK.
Bit 4=1: The PLC has the option of requesting a T preparation again with changed
parameters.
The acknowledgment states "2", "7" und "103" are enabled with this bit. The tool
selection is then recalculated in the NCK.
Bit 5 to bit 8
Bit 5 and bit 7 refer to the main spindle
Bit 6 und bit 8 refer to secondary spindles
Bit 5 = 1: The command is regarded as output when the internal transport acknowledgment
+ the transport acknowledgment are present, that is, when the command has been
accepted by the basic PLC program.
(Bit 19=1 also allows the block change to be prevented (main run) until the required
acknowledgments have been received.)
Bit 7 = 1: The output of the command is not regarded as being completed until the end
acknowledgment has been received from the PLC. That is, the command has beren
acknowledged by the PLC user program with status "1".
(Bit 19=1 also allows the block change to be prevented (main run) until the required
acknowledgments have been received.)
Bit 5 and bit 7 (alternatively bit 6 and bit 8) are mutually exclusive.
Only the following combinations are permissible:
Bit 5: ...0...1...0
Bit 7: ...0...0...1
With the default setting, that is bits 5 to 8 = 0, synchronisation takes place in the
block in which a cutting edge is selected for the first time.
Setting these bits delays the block processing.
Bit 9 to bit 11
Bit 9: Reserved for test purposes
It can also be used by machine manufacturers during the test phase, provided that the
PLC program does not yet control the tool change.
Bit 10=1: M06 is delayed until the preparation has been accepted by the PLC user
program.
The change command is not output until the preparation acknowledgment has been
received. That can be, for example, status "1" or "105".
Machine data
3.3 Channel-specific machine data
Parameter Manual
140 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
