20482 COMPRESSOR_MODE EXP F2
- Mode of compressor DWORD NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 1333 1/1 M
808d-me62 - 300 0 1333 1/1 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 1333 0/0 S
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 1333 0/0 S
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 1333 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 1333 7/7 U
Description: This MD is used to set the compressor operating mode.
The units digits, the tens digits and the hundreds digits have different meanings.
The following options are available:
Units digits:
0: With the compressor, the tolerances specified with MD33100 $MA_COMPRESS_POS_TOL
are met for all axes (geometry and orientation axes).
1: With the compressor, the contour tolerances specified with SD42475
$SC_COMPRESS_CONTUR_TOL are active for the geometry axes.
For the orientation axes, the axis-specific tolerances MD33100 $MA_COMPRESS_POS_TOL
are active.
2: With the compressor, the axis-specific tolerances MD33100 $MA_COMPRESS_POS_TOL
become active for the geometry axes. The orientation movement is compressed in
compliance with the maximum angular deviations specified with SD42476
$SC_COMPRESS_ORI_TOL or SD42477 $SC_COMPRESS_ORI_ROT_TOL.
3: With the compressor, the contour tolerance SD42475 $SC_COMPRESS_CONTUR_TOL
becomes active for the geometry axes and the maximum angular deviation SD42476
$SC_COMPRESS_ORI_TOL or SD42477 $SC_COMPRESS_ORI_ROT_TOL becomes active for the
orientation axes.
Tens digits:
The tens digits of this MD can be used to set a compressor response that is compatible
with previous software releases (< SW 6.3).
0x: All blocks with orientations and value assignments are compressed.
This is the default setting.
Notice: This response is incompatible with previous software releases!
1x: Blocks with value assignments are not compressed (e.g. X=100 ..., etc.)
2x: Blocks with a programmed tool orientation are not compressed.
(e.g. A3= B3= C3=).
3x: All blocks with value assignments and/or programmed tool orientation are not
compressed.
With this
setting, the response is fully compatible with previous software
releases (< 6.3).
Hundreds digits:
The hundreds digit can be used to set which blocks in addition to G01 blocks are to be
compressed or not:
0xx: Circular blocks and G00 blocks are not compressed. Is compatible with previous
releases.
1xx: Circular blocks are linearized and compressed by COMPCAD.
2xx: G00 blocks are compressed; a different tolerance may be applied here (see MD 20560
$MC_G0_TOLERANCE_FACTOR).
3xx: Combination of the two previous options: Both circular blocks and G00 blocks are
compressed.
The thousands digits optimize the compressor for different machine types:
0xxx: Optimization for a good surface quality in tool and mold building.
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 149
