Siemens SINUMERIK 808D ADVANCED Parameter Manual

20560 G0_TOLERANCE_FACTOR EXP B1
- Tolerance factor for G00 DOUBLE NEW CONF
-
808d-me42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1 M
808d-me62 - 3.0 1.e-9 - 1/1 M
808d-te42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1 M
808d-te62 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1 M
808d-mte40 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1 M
808d-mte60 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
1.e-9 - 1/1 M
Description: Tolerance factor for G00.
This factor is used to make different settings for the tolerances for processing when
G00 is active (rapid traverse, infeed motion).
This tolerance factor is relevant for the following control functions:
1. Compressor (COMPCAD, COMPCURV, and COMPON)
2. Smoothing with G64x
3. Smoothing of orientation with OST
4. Smoothing of orientation response with ORISON
This factor can be both greater than 1 and less than 1. However, higher tolerance
settings are usual for infeed motion.
If the factor is equal to 1, the tolerances applied for G00 motion are the same as
those for non-G00 motion.
20600 MAX_PATH_JERK C05 B1, B2
m/s³ Path-related maximum jerk DOUBLE NEW CONF
-
808d-me42 5 1.e6, 1.e6, 1.e6, 1.e6,
1.e6
1.e-9 - 0/0 S
808d-me62 5 10000., 10000.,
10000., 10000., 10000.
1.e-9 - 1/1 M
808d-te42 5 1.e6, 1.e6, 1.e6, 1.e6,
1.e6
1.e-9 - 0/0 S
808d-te62 5 10000., 10000.,
10000., 10000., 10000.
1.e-9 - 1/1 M
808d-mte40 5 100., 100., 100., 100.,
100., 100., 100., 100.,
100., 100., 100....
1.e-9 - 7/2 M
808d-mte60 5 100., 100., 100., 100.,
100., 100., 100., 100.,
100., 100., 100....
1.e-9 - 7/2 M
Description: The jerk limitation restricts the path acceleration change in SOFT mode. The path
acceleration divided by the jerk limitation value produces a time in which the
acceleration change takes place.
The jerk limitation is activated on the path by the NC command SOFT, and deactivated
by BRISK.
MD irrelevant for:
Error states that lead to a rapid stop. In addition, the limitation is also inactive
for positioning axes.
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 153
