Bit 15 = 0:
If an axis with active diameter programming is traversed in the channel, only half the
distance of the specified increment is traveled during handwheel travel (MD11346
$MN_HANDWH_TRUE_DISTANCE = 1 or 3
Bit 15 = 1:
If an axis with active diameter programming is traversed in the channel, the specified
increment
is fully
traveled during handwheel travel (MD11346 $MN_HANDWH_TRUE_DISTANCE
= 1 or 3).
Bit 16 = 0:
Return traveling is possible to the start of the block.
Bit 16 = 1:
Return traveling is not possible (response as at start of block, i.e. pulses are
ignored).
20700 REFP_NC_START_LOCK C01, C03 D1, R1, Z1
- NC start disable without reference point BYTE Reset
-
- - 1, 1, 1, 1, 1, 1, 1, 1... 0 2 2/2 M
Description: 0: The NC/PLC interface signal DB3200 DBX7.1 (NC start) for starting part programs
or part program blocks (MDI and overstore) is active even if one or all axes of the
channel have not yet been referenced.
To ensure that the axes nevertheless reach the correct position after NC startup, the
work (workpiece coordinate
system = work) must be set to the correct value by means of
other methods (scratch method, automatic work offset determination etc.).
1: Axes for which the axial MD34110 $MA_REFP_CYCLE_NR specifies that a reference
point is mandatory (value > -1), must be referenced for NC startup to be enabled.
2: Advanced form of setting 1 in that the axis state "Position restored" (instead
of "referenced") is sufficient for NC startup in MDI or overstore.
20730 G0_LINEAR_MODE C09 P2
- G0 interpolation mode BOOLEAN PowerOn
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 2/2 M
Description: This machine data defines the interpolation behavior of G0:
0: Non-linear interpolation (RTLIOF): Each path axis interpolates as an individual
axis (positioning axis), independently of the other axes, at the rapid traverse
velocity of the axis (MD32000 $MA_MAX_AX_VELO).
1: Linear interpolation (RTLION): The path axes are interpolated jointly.
20734 EXTERN_FUNCTION_MASK N12 -
- Function mask for external language DWORD Reset
-
808d-me42 - 0x4800 0 0xFFFF 1/1 M
808d-me62 - 0x4800 0 0xFFFF 1/1 M
808d-te42 - 0x4800 0 0xFFFF 1/1 M
808d-te62 - 0x4800 0 0xFFFF 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xFFFF 1/1 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xFFFF 1/1 M
Description: This machine data is used to influence functions in ISO mode.
Bit0: 0:
Machine data
3.3 Channel-specific machine data
Parameter Manual
158 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
