32750 TEMP_COMP_TYPE A09 K3, W1
- Temperature compensation type BYTE PowerOn
CTEQ
808d-me42 - 0 0 0x7 ReadOnly
808d-me62 - 0 0 0x7 ReadOnly
808d-te42 - 0 0 0x7 ReadOnly
808d-te62 - 0 0 0x7 ReadOnly
808d-mte40 - 0 0 0x7 7/2
808d-mte60 - 0 0 0x7 7/2
Description: The type of temperature compensation applicable to the machine axis is activated in
MD32750 $MA_TEMP_COMP_TYPE.
A distinction is made between the following types:
Bit 0 = 0:
Position-independent temperature compensation not active
Bit 0 = 1:
Position-independent temperature compensation active
Bit 1 = 0:
Position-dependent temperature compensation not active
Bit 1 = 1:
Position-dependent temperature compensation active
Bit 2 = 0:
Temperature compensation not active in tool direction
Bit 2 = 1:
Temperature compensation active in tool direction
Related to:
SD43900 $SA_TEMP_COMP_ABS_VALUE
Position-dependent temperature compensation value
SD43920 $SA_TEMP_COMP_REF_POSITION
Reference point for position-dependent temperature compensation
SD43910 $SA_TEMP_COMP_SLOPE
Gradient for position-dependent temperature compensation
MD32760 $MA_COMP_ADD_VELO_FACTOR
Excessive velocity due to compensation
32760 COMP_ADD_VELO_FACTOR EXP, A09, A04 K3
- Excessive velocity due to compensation DOUBLE NEW CONF
CTEQ
- - 0.01 0. 0.10 1/1
Description: The maximum distance that can be traversed because of temperature compensation in one
IPO cycle can be limited by the axial MD32760 $MA_COMP_ADD_VELO_FACTOR.
If the resulting temperature compensation value is above this maximum, it is traversed
over several IPO cycles. There is no alarm.
The maximum compensation value per IPO cycle is specified as a factor referring to the
maximum axis velocity (MD32000 $MA_MAX_AX_VELO).
The maximum gradient of the temperature compensation tanbmax is also limited with this
machine data.
Example of calculation of the maximum gradient tanb(max):
1. Calculation of the interpolator cycle time (see Description of Functions
Velocities, Setpoint/Actual Value Systems, Cycle Times (G2))
Machine data
3.4 Axis-specific machine data
Parameter Manual
252 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
