MD is Corresponds with:
MD20850 $MC_SPOS_TO_VDI
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET
MD35020 $MA_SPIND_DEFAULT_MODE
SD43200 $SA_SPIND_S
35040 SPIND_ACTIVE_AFTER_RESET A06, A10 S1, Z1, 2.7
- Own spindle RESET BYTE PowerOn
CTEQ
808d-me42 - 2 0 2 1/1
808d-me62 - 2 0 2 1/1
808d-te42 - 2 0 2 1/1
808d-te62 - 2 0 2 1/1
808d-mte40 - 0 0 2 1/1
808d-mte60 - 0 0 2 1/1
Description: MD35040 $MA_SPIND_ACTIVE_AFTER_RESET defines the response of the spindle after channel
reset NC/PLC interface signal DB3000 DBX0.7 (Reset) and program end (M2, M30).
This MD is only active in the spindle mode open-loop control mode. In positioning mode
or oscillation mode, the spindle is always stopped.
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET = 0:
● Spindle stops (with M2/M30 and channel and mode group reset).
● Program is canceled.
● For spindle mode, the programmed ACC and VELOLIM are reset to 100% if MD22400
$MC_S_VALUES_ACTIVE_AFTER_RESET and the axis-specific MD32320
$MA_DYN_LIMIT_RESET_MASK do not specify anything else.
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET= 1:
● Spindle does not stop.
● Program is canceled.
● For spindle mode, the programmed ACC and VELOLIM are retained.
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET= 2:
● Spindle does not stop at the M function configured via MD10714 $MN_M_NO_FCT_EOP
(e.g. M32).
● However, the spindle stops at channel or mode group reset.
● For spindle mode, the programmed ACC and VELOLIM are retained.
The NC/PLC interface signal DB380x DBX2.2 (Delete distance-to-go/Spindle reset) is
always effective, independent of MD35040 $MA_SPIND_ACTIVE_AFTER_RESET.
Not relevant to:
● Spindle modes other than open-loop control mode.
Related to:
NC/PLC interface signal DB3000 DBX0.7 (Reset)
NC/PLC interface signal DB380x DBX2.2 (Delete distance-to-go/Spindle reset)
35090 NUM_GEAR_STEPS A06, A10 S1
- Number of gear stages DWORD Reset
-
- - 5 1 5 1/1
Description: Number of set gear stages.
The first gear stage is always available.
Corresponding MDs:
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stages available/functions)
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 271
