● The configured speed cannot exceed the value from MD35100 $MA_SPIND_VELO_LIMIT.
● If position control
is active for the spindle, the speed is limited to the maximum
speed of MD35135 $MA_GEAR_STEP_PC_MAX_VELO_LIMIT.
● The NC/PLC interface signal "Setpoint speed limited" is set to indicate that the
speed is being limited.
● The maximum speed entered here has no effect on the automatic gear stage selection
M40 S..
● The upper switching threshold for the automatic gear stage selection M40 is
configured in MD35110 $MA_GEAR_STEP_MAX_VELO.
Related to:
MD35135 $MA_GEAR_STEP_PC_MAX_VELO_LIMIT (maximum speed of the gear stage with position
control)
MD35140 $MA_GEAR_STEP_MIN_VELO_LIMIT (minimum speed of the gear stage)
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stage selection is possible)
MD35110 $MA_GEAR_STEP_MAX_VELO (max. speed for automatic gear stage selection M40)
MD35120 $MA_GEAR_STEP_MIN_VELO (min. speed for automatic gear stage selection M40)
35135 GEAR_STEP_PC_MAX_VELO_LIMIT A06, A11, A04 S1
rev/min Maximum speed of the gear stage with position control DOUBLE NEW CONF
CTEQ
- 6 0., 0., 0., 0., 0., 0. 0 - 2/2
Description: The maximum speed of the current gear stage is configured in MD35135
$MA_GEAR_STEP_PC_MAX_VELO_LIMIT with position control active. The speed setpoints
generated taking the override into account are limited to this speed.
If a value of 0 is set (default), 90% of the value from MD35130
$MA_GEAR_STEP_MAX_VELO_LIMIT will become the maximum speed with position control
active.
Note:
● The configured speed cannot exceed the value from MD35100 $MA_SPIND_VELO_LIMIT.
● The NC/PLC interface signal "Setpoint speed limited" is set to indicate that the
speed is being limited.
● The
maximum speed
entered here has no effect on the automatic gear stage selection
M40 S..
● The upper switching threshold for the automatic gear stage selection M40 is
configured in MD35110 $MA_GEAR_STEP_MAX_VELO.
Related to:
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT (maximum speed of the gear stage with spee
control)
MD35140 $MA_GEAR_STEP_MIN_VELO_LIMIT (minimum speed of the gear stage)
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stage selection is possible)
MD35110 $MA_GEAR_STEP_MAX_VELO (max. speed for automatic gear stage selection M40)
MD35120 $MA_GEAR_STEP_MIN_VELO (min. speed for automatic gear stage selection M40)
35140 GEAR_STEP_MIN_VELO_LIMIT A06, A11, A04 S1, V1
rev/min Minimum speed of gear stage DOUBLE NEW CONF
CTEQ
- 6 5., 5., 10., 20., 40., 80. 0.0 - 2/2
Description: The minimum speed of the current gear stage is configured in MD35140
$MA_GEAR_STEP_MIN_VELO_LIMIT. The minimum speed is applied only if the spindle is in
speed control mode.
The speed setpoints generated taking the override into account do
not undershoot the minimum speed.
Note:
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 275
