808d-mte40 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: $SN_CEC_0[t] and $SN_CEC_1[t] can be calculated absolutely or additively:
FALSE: Absolute, the calculated values of $SN_CEC_0[t] and $SN_CEC_1[t] are included
as absolute values.
TRUE: Additive, the calculated values of $SN_CEC_0[t] and $SN_CEC_1[t] are added to
the existing values.
Related to ....
$SN_CEC_BAS_0[t], $SN_CEC_BAS_1[t] distance to measuring point in the basic axis
$SN_CEC_COMP_0[t], $SN_CEC_COMP_1[t] cylinder error in the compensation axis
42000 THREAD_START_ANGLE - K1
degrees Starting angle for thread DOUBLE Immediately
-
- - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 7/7 U
Description: In the case of multiple thread cutting, the offset of the individual threads can be
programmed with the aid of this setting data.
This SD can be changed by the part program with the command SF.
Note:
MD10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
42010 THREAD_RAMP_DISP - V1
mm Acceleration behavior of axis when thread cutting DOUBLE Immediately
-
808d-me42 2 -1., -1., -1., -1., -1., -1.,
-1., -1., -1., -1., -1., -1.,
-1.,...
-1. 999999. 3/3 U
808d-me62 2 -1., -1., -1., -1., -1., -1.,
-1., -1., -1., -1., -1., -1.,
-1.,...
-1. 999999. 3/3 U
808d-te42 2 -1., -1., -1., -1., -1., -1.,
-1., -1., -1., -1., -1., -1.,
-1.,...
-1. 999999. 3/3 U
808d-te62 2 -1., -1., -1., -1., -1., -1.,
-1., -1., -1., -1., -1., -1.,
-1.,...
-1. 999999. 3/3 U
808d-mte40 2 -1., -1., -1., -1., -1., -1.,
-1., -1., -1., -1., -1., -1.,
-1.,...
-1. 999999. 7/7 U
808d-mte60 2 -1., -1., -1., -1., -1., -1.,
-1., -1., -1., -1., -1., -1.,
-1.,...
-1. 999999. 7/7 U
Description: The SD is active for thread cutting with G33 (G34, G35).
It features two elements that define the behavior of the thread axis during runup (1st
element) and during deceleration/smoothing (2nd element).
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 307
