MD28072 $MC_MM_MAXNUM_SURF_GROUPS
42475 COMPRESS_CONTUR_TOL - F2, PGA
mm Maximum contour deviation with compressor DOUBLE Immediately
-
808d-me42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-me62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-te42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-te62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-mte40 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 7/7 U
808d-mte60 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 7/7 U
Description: This setting data defines the maximum contour tolerance in the compressor.
42477 COMPRESS_ORI_ROT_TOL - F2, PGA
degrees Maximum deviation of tool rotation with compressor DOUBLE Immediately
-
808d-me42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-me62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-te42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-te62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-mte40 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 7/7 U
808d-mte60 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 7/7 U
Description: This setting data defines the maximum tolerance in the compressor for turning the tool
orientation. This data defines the maximum permissible angular displacement of the
tool rotation.
This data is only active if an orientation transformation is active.
Turning the tool orientation is only possible with 6-axis machines.
42480 STOP_CUTCOM_STOPRE - W1
- Alarm response with tool radius compensation and preproc. stop BOOLEAN Immediately
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 3/3 U
Description: If this setting data is TRUE, block execution is stopped by preprocessing stop and
active tool radius compensation, and does not resume until after a user
acknowledgement (START).
If it is FALSE, machining is not interrupted at such a program point.
NC setting data
Parameter Manual
318 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
