CASE B: In the same situation as described above, the point of intersection is chosen
that is located
on the first partial contour nearer to the block end, but only if the
absolute value of the contour violation caused by this is less than the effective
contour tolerance. For the effective contour tolerance, see the description "Contour/
orientation tolerance" in FB1. The currently effective tolerance can be read with
$AC_CTOL. If a tolerance of zero is programmed in this way, a permanently assigned
tolerance of 0.002mm applies.
The tolerance value is applied that is valid for activation of the tool radius
correction with G41 or G42.
42500 SD_MAX_PATH_ACCEL - B2
m/s² Maximum path acceleration DOUBLE Immediately
-
808d-me42 - 10000., 10000.,
10000., 10000.,
10000., 10000.,
10000., 10000....
1.0e-6 - 1/1 M
808d-me62 - 10000., 10000.,
10000., 10000.,
10000., 10000.,
10000., 10000....
1.0e-6 - 1/1 M
808d-te42 - 10000., 10000.,
10000., 10000.,
10000., 10000.,
10000., 10000....
1.0e-6 - 1/1 M
808d-te62 - 10000., 10000.,
10000., 10000.,
10000., 10000.,
10000., 10000....
1.0e-6 - 1/1 M
808d-mte40 - 10000., 10000.,
10000., 10000.,
10000., 10000.,
10000., 10000....
1.0e-6 - 7/7 U
808d-mte60 - 10000., 10000.,
10000., 10000.,
10000., 10000.,
10000., 10000....
1.0e-6 - 7/7 U
Description: Setting data for additional limitation of (tangential) path acceleration
Related to ...
MD32300 $MA_MAX_AX_ACCEL
SD42502 $SC_IS_SD_MAX_PATH_ACCEL
42502 IS_SD_MAX_PATH_ACCEL - B2
- Evaluate SD42500 $SC_SD_MAX_PATH_ACCEL BOOLEAN Immediately
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 321
