42512 IS_SD_MAX_PATH_JERK - B2
- Evaluate SD42510 $SC_SD_MAX_PATH_JERK BOOLEAN Immediately
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: SD42510 $SC_SD_MAX_PATH_JERK is included in the limit calculations if SD42512
$SC_IS_SD_MAX_PATH_JERK=TRUE
Related to ...
SD42510 $SC_SD_MAX_PATH_JERK (SD for additional limitation of (tangential) path jerk)
42520 CORNER_SLOWDOWN_START - -
mm Start of feed reduction at G62. DOUBLE Immediately
-
808d-me42 - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 1/1 M
808d-me62 - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 1/1 M
808d-te42 - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 1/1 M
808d-te62 - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 1/1 M
808d-mte40 - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 7/7 U
808d-mte60 - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 7/7 U
Description: Traverse path distance from which the feed is reduced before the corner with G62.
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 323
