808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Position of the oscillating axis at reversal point 1.
Note:
MD10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after RESET.)
Application example(s)
NC language: OSP1[Axis]=Position
Related to ....
SD43710 $SA_OSCILL_REVERSE_POS2
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43710 OSCILL_REVERSE_POS2 - P5
mm, degrees Oscillation reversal point 2 DOUBLE Immediately
-
808d-me42 - 0.0 - - 7/7 U
808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Position of the oscillating axis at reversal point 2.
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Application example(s)
NC language: OSP2[Axis]=Position
Related to ....
SD43700 $SA_OSCILL_REVERSE_POS1
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43720 OSCILL_DWELL_TIME1 - P5
s Hold time at oscillation reversal point 1 DOUBLE Immediately
-
808d-me42 - 0.0 - - 7/7 U
808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Hold time of the oscillating axis at reversal point 1.
Note:
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 347
