10136 DISPLAY_MODE_POSITION N01 -
- Display mode for actual position in the work DWORD Reset
-
808d-me42 - 1 0 1 1/1
808d-me62 - 1 0 1 1/1
808d-te42 - 1 0 1 1/1
808d-te62 - 1 0 1 1/1
808d-mte40 - 0 0 1 1/1
808d-mte60 - 0 0 1 1/1
Description: Defines how the position and the distance to go are displayed in the Work.
0: Display as in software version 5 and earlier
1: At end of block, the actual value display is in principle the same as the
programmed
end point,
irrespective of where the machine actually is (e.g. as a result
of the tool radius compensation). The distance to go is the same as the actual distance
to be traversed. This means that the displayed actual postion has to be the same as
the displayed end position minus the distance to go, irrespective of the actual
machine position. If the block end points are changed by chamfers, radii, contour
definitions, splines or SAR in comparison to the NC programm, then these changes are
reflected in the display as if thay had been programmed. This does not apply to changes
resulting from tool radius compensation or smoothing.
10160 PREP_COM_TASK_CYCLE_RATIO EXP, N01 ECO
- Factor for communication with HMI DWORD PowerOn
-
808d-me42 - 3 1 50 0/0
808d-me62 - 3 1 50 0/0
808d-te42 - 3 1 50 0/0
808d-te62 - 3 1 50 0/0
808d-mte40 - 3 1 50 7/1
808d-mte60 - 3 1 50 7/1
Description: This machine data specifies the division ratio used for activating the communication
task in the non-cyclic time level. This allows the time share of preparation in the
non-cyclic time level to be increased, which reduces block cycle times. External
communication (file transfer) is slowed down in particular during program execution
(block reload).
10175 PLC_TASK_RUNTIME_WARNING EXP, N01 ECO
s Prewarning limit for computation time exceeded SW-PLC2xx DOUBLE PowerOn
-
- - 0.000393 0.0 0.000436 1/1
Description: The machine data defines the duration for the prewarning of the computation time
exceeded for SW-PLC2xx in seconds. After this time has expired, SW-PLC2xx generates
display alarm 400026 "PLC cycle time has exceeded the alarm threshold".
10192 GEAR_CHANGE_WAIT_TIME N01 S1
s Gear stage change waiting time DOUBLE PowerOn
-
- - 10.0 0.0 1.0e5 1/1
Description: External events which trigger reorganization, wait for the end of a gear stage change.
GEAR_CHANGE_WAIT_TIME now determines
the waiting time for the gear stage change. Time
unit in seconds.
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 35
