Signal state 1 or edge
change 0 → 1
The input range is only used if IS "INC inputs active in the mode area" (DB2600
DBX1.0) is set. These signals are valid for all axes and geometry axes.
With the IS
"INC..." it is defined by how many increments the axis moves when
actuating the traversing key or when rotating the handwheel for each grid
position. In this case, the JOG mode must be active. For "var. INC", the value
generally applies in SD41010 JOG_VAR_INCR_SIZE.
For "continuous" the associated axis can be traversed with the plus or minus
traversing key by keeping the traversing key pressed.
As soon as the selected machine function becomes active, this is signaled to
the PLC interface (IS "Active machine function 1 INC; ..." ). If several machine
function signals (1 INC, INC... or "Continuous traversing") are selected at the
interface simultaneously, then no machine function is activated by the control.
Note:
The input IS "INC..." or "continuous" to change an active machine function
must be present for at least one PLC cycle. A steady-state signal is not re‐
quired.
Signal state 0 or edge
change 1 → 0
The machine function in question is not selected. No change is requested to
the active machine function.
If an axis
is currently traversing an increment, this movement is also aborted
if this machine function is deselected or switched over.
corresponding to ... IS "INC inputs active in the mode area" (DB2600 DBX1.0)
IS "Machine function 1 INC, ..., continuous"
for axis 1 in the Work (DB3200 DBX1001.0 to .6)
for axis 2 in the Work (DB3200 DBX1005.0 to .6)
for axis 3 in the Work (DB3200 DBX1009.0 to .6)
IS "Machine function
1 INC, ..., continuous" in the axis area (DB380x DBX5.0
to .6)
IS "Active machine function 1 INC, ..., continuous"
for axis 1 in the Work (DB3300 DBX1001.0 to .6)
for axis 2 in the Work (DB3300 DBX1005.0 to .6)
for axis 3 in the Work (DB3300 DBX1005.0 to .6)
IS "Active machine function 1 INC, ..., continuous" in the axis area (DB390x
DBX5.0 to .6)
Note for the reader Function Manual Basic Functions H1
DB3100
DBX0.0
Active AUTOMATIC mode
Signal(s) from NCK (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
AUTOMATIC mode is active.
Signal state 0 or edge
change 1 → 0
AUTOMATIC mode is not active.
Note for the reader Function Manual Basic Functions K1
DB3100
DBX0.1
Active MDI mode
Signal(s) from NCK (NCK → PLC)
Edge evaluation: Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
MDI mode is active.
Detailed descriptions of interface signals
5.6 Mode signals
Parameter Manual
374 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
