Corresponding to ... DB2700 DBX3.0 (NCK alarm present)
Note for the reader /DA/ Diagnostics Guide
DB3300
DBX5.0
DBX5.1
Handwheel 1 active as contour handwheel
Handwheel 2 active as contour handwheel
Edge evaluation: No Signal(s) updated: Cyclic
Description These signals show which handwheel is selected as contour handwheel:
Signal = 1 Handwheel x is selected as contour handwheel.
Signal = 0 Handwheel x is deselected as contour hand‐
wheel.
Special cases,
errors, ...
The signal is kept beyond an NC Reset.
Corresponding to ... DB3200.DBX14.0, DBX14.1 (handwheel x active as contour handwheel)
DB3300
DBX7.5
Handwheel direction of rotation inversion active for contour handwheel
Edge evaluation: No Signal(s) updated: Cyclic
Description This signal indicates whether the direction of rotation was inverted for the
contour handwheel:
Signal = 1 The direction of rotation of the contour hand‐
wheel is inverted.
Signal = 0 The direction of rotation of the contour hand‐
wheel is not inverted.
Corresponding to ... DB3200.DBX14.0, DBX14.1 (handwheel x active as contour handwheel)
DB3300
DBX1000.0 and .1
DBX1004.0 and .1
DBX1008.0 and .1
Handwheel active (1 to 2)
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 These PLC interface signals are used to define whether this geometry axis
is assigned to handwheel 1/2 or is not assigned to any handwheel.
Only one handwheel can be assigned to an axis at any one time.
If several interface signals "activate handwheel" are set, then 'Handwheel
1' has a higher priority than 'Handwheel 2'.
If the assignment is active, then the geometry axis can be traversed using
the handwheel in the JOG mode.
Signal status This geometry axis is not assigned to handwheel 1/2.
Corresponding to ... IS "Activate handwheel" (DB3200 DBX1000.0/.1,
DB3200 DBX1004.0/.1, DB3200 DBX1008.0/.1)
Note for the reader Function Manual Basic Functions H1
Detailed descriptions of interface signals
5.7 Channel-specific signals
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 399
