Signal state 1 The axis-specific feedrate override is entered from the PLC gray-coded.
Gray coding for axis-specific feedrate override
Switch set‐
ting
Code
Axial feedrate override
factor
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
00001
00011
00010
00110
00111
00101
00100
01100
01101
01111
01110
01010
01011
01001
01000
11000
11001
11011
11010
11110
11111
11101
11100
10100
10101
10111
10110
10010
10011
10001
10000
0.0
0.01
0.02
0.04
0.06
0.08
0.10
0.20
0.30
0.40
0.50
0.60
0.70
0.75
0.80
0.85
0.90
0.95
1.00
1.05
1.10
1.15
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
corresponding to ... IS "Override active" (DB380x DBX1.7)
Note for the reader Function Manual Basic Functions V1
DB380x
DBX1.3
Axis/spindle disable
Signal(s) to axis/spindle (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
