corresponding to ... MD34100 REFP_SET_POS (reference point value)
MD36050 CLAMP_POS_TOL (clamping tolerance)
Note for the reader Function Manual Basic Functions R1
DB380x
DBX3.1
Enable travel to fixed stop
Signal(s) to axis / spindle (PLC → NCK)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Meaning when the "FXS" function is selected via part program,
(IS "Activate travel to fixed stop" = 1):
Travel to fixed
stop is enabled and the axis traverses from the start position
at the programmed velocity to the programmed target position.
Signal state 0 Meaning when function "FXS" is selected via part program
(IS "Activate travel to fixed stop" = 1):
→ Travel to fixed stop is locked.
→ The axis remains at the start position with reduced torque.
→ The channel message "Wait: Aux fct ackn missing" is displayed.
Edge change 1 → 0 Meaning before the fixed stop has been reached
IS "Fixed stop reached" = 0.
→ Travel to fixed stop is interrupted
→ Alarm "20094: Axis%1 function was aborted" is displayed
Meaning once fixed stop has been reached
IS "Fixed stop reached" = 1.
Torque limiting and the monitoring of the fixed stop monitoring window are
canceled.
IS irrelevant for ... MD 37060: FIXED_STOP_ACKN_MASK (observing PLC acknowledgments
for travel to fixed stop) = 0 or 2
corresponding to ... MD 37060: FIXED_STOP_ACKN_MASK (observe PLC acknowledgments
for travel to fixed stop)
IS "Activate travel to fixed stop"
Note for the reader Function Manual Basic Functions F1
DB380x
DBX3.6
Velocity / spindle speed limitation
Signal(s)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The NCK limits the velocity / spindle speed to the limit value set in MD35160
SPIND_EXTERN_VELO_LIMIT.
Signal state 0 No limiting active.
corresponding to ... MD35100 SPIND_VELO_LIMIT (max. spindle speed)
SD43220 SPIND_MAX_VELO_G26 (prog. spindle speed limit G26)
SD43230 SPIND_MAX_VELO_LIMIT (spindle speed limit G96)
Note for the reader Function Manual Basic Functions A3
DB380x
DBX4.0 to .1
Activate handwheel (1 to 2)
Signal(s) to axis / spindle (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
414 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
