Drive basic list on HMI
Par. No. Name Min Max Factory
setting
Unit Data type Effective Can be
changed
p0977 Save all parameters 0 1013 [0] 0 - U16 IM T, U
Description:
Saves all parameters of the drive system to the non-volatile memory. When saving, only the adjustable pa‐
rameters intended to be saved are taken into account.
Dependency: p0976
Caution:
Memory card inserted:
The drive parameterization is also saved on the card. Any backed-up data is overwritten!
Notice:
The Control Unit power supply may only be powered down after data has been saved (i.e. after data save
has been started, wait until the parameter again has the value 0). Writing to parameters is inhibited while
saving.
Note:
Parameters saved with p0977 = 10, 11 or 12 can be downloaded again with p0976 = 10, 11 or 12.
p1460[0...n] Speed controller P gain adap‐
tation speed lower
0.000 999999.0
00
0.300 Nms/
rad
Float IM T, U
Description:
Sets
the P
gain of the speed controller before the adaptation speed range (0 ... p1464). This value corresponds
to the basic setting of the P gain of the speed controller without adaptation (p1461 = 100 %).
Dependency: p1461
Note:
When automatically calculating the speed controller, only the motor moment of inertia is taken into account
(p0341). For higher load moments of inertia (p0342 > 1 or p1498 > 0), you are advised to check the speed
controller gain.
p1461[0...n] Speed controller Kp adapta‐
tion speed upper scaling
0.0 200000.0 [0]
100.0
[%] Float IM T, U
Description:
Sets the P gain of the speed controller for the upper adaptation speed range (> p1465). The entry is made
referred to the P gain for the lower adaptation speed range of the speed controller (% referred to p1460).
Dependency: p1460
Note:
When automatically calculating the speed controller, only the motor moment of inertia is taken into account
(p0341). For higher load moments of inertia (p0342 > 1 or p1498 > 0), you are advised to check the speed
controller gain.
p1462 Speed controller integral time
adaptation speed lower
0.00 100000.0
0
20.00 ms Float IM T, U
Description:
Sets the integration time of the speed controller before the adaptation speed range (0 ... p1464).
This value corresponds to the basic setting of the integral time of the speed controller without adaptation
(p1461 = 100 %).
Dependency: p1463
SINAMICS V70 parameters
7.3 Drive basic list on HMI
Parameter Manual
496 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
